Product Summary

The EMIF03-SIM01 is a highly integrated devices designed to suppress EMI/RFI noise in all systems subjected to electromagnetic interferences. The EMIF03 Flip Chip packaging means the package size is equal to the die size. The EMIF03-SIM01 includes an ESD protection circuitry which prevents the device from destruction when subjected to ESD surges up 15kV. The EMIF03-SIM01 is used to proivde EMI filtering and ESD protection for SIM Interface (Subscriber Identify Module) and UIM Interface (Universal Identify Module).

Parametrics

EMIF03-SIM01 absolute maximum ratings: (1)Tj, Maximum junction temperature: 125 ℃; (2)Top, Operating temperature range: - 40 to + 85 ℃; (3)Tstg, Storage temperature range: - 55 to 150 ℃.

Features

EMIF03-SIM01 features: (1)EMI symmetrical (I/O) low-pass filter; (2)High efficiency in EMI filtering; (3)Very low PCB space consuming: 1.57 mm x 1.57 mm; (4)Very thin package: 0.65 mm; (5)High efficiency in ESD suppression; (6)High reliability offered by monolithic integration; (7)High reducing of parasitic elements through integration & wafer level packaging.

Diagrams

EMIF03-SIM01 circuit diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
EMIF03-SIM01
EMIF03-SIM01

STMicroelectronics

ESD Suppressors EMI Filter w/ESD Pro

Data Sheet

Negotiable
EMIF03-SIM01F2
EMIF03-SIM01F2

STMicroelectronics

ESD Suppressors unidirect 3line fltr 35pF -35db @ 900MHz

Data Sheet

0-3950: $0.22
3950-5000: $0.22
5000-10000: $0.21
